Premium Industrial Gate Lock for 30-50mm Box Sections with Stainless Steel Mechanism and Easy Installation

Product Overview

This Premium Industrial Gate Lock is designed to fit 30-50mm box sections, providing security and ease of use. Known for its high quality and attractive design, it is perfect for various applications.

Key Features

• Color: Black RAL 9005
• Includes black ornate handles
• ISO 9227 KTL / E-coated lockbox withstands 1000 hours of salt spray testing
• Self-latching daybolt easily adjustable for left or right installation
• Deadbolt throw of 23 mm in a single turn of the key
• Key-operated self-latching bolt for enhanced security
• 4-hole fixing with two hexagon socket head screws for easy installation
• Center distance bolts: 60 mm
• Bolts can be adjusted up to 20 mm continuously without dismounting the lockbox
• Durable stainless steel mechanism for long-lasting performance

Dimensions & Specifications

Specification	Measurement
Suitable Section Size	30-50mm
Deadbolt Throw	23 mm
Center Distance Bolts	60 mm
Adjustment Range	Up to 20 mm
weight	1.54 kg
length	160.0mm
width	90.0mm
depth	31.0mm

Technical Specifications

• Material: Stainless Steel
• Coating: E-coating for corrosion resistance
• Installation Type: Left or Right changing of self-latching bolt
• Fixing Method: 4-hole fixing

FAQ

Q: Can this lock be installed on any gate?

A: This lock is specifically designed for gates with 30-50mm box sections.

Q: Is the lock weather-resistant?

A: Yes, the E-coated lockbox is tested to withstand 1000 hours of salt spray, making it suitable for outdoor use.

Q: Can I adjust the lock after installation?

A: Yes, the bolts can be adjusted up to 20 mm without dismounting the lockbox.
