Premium Adjustable Aluminium Channel Base for Glass 12mm to 21.52mm - 5000mm Long with Easy Adjustment System

Product Overview

This Premium Adjustable Aluminium Channel Base is designed to accommodate glass panels ranging from 12mm to 21.52mm in thickness. With a length of 5000mm, it provides a versatile solution for various glass installation applications.

Features

• Length: 5000mm
• Glass Thickness Compatibility: 12mm to 21.52mm
• 38mm of adjustment available for easy glass alignment
• Innovative rotating wedge system for precise adjustments

Benefits

The adjustable feature allows for quick and easy adjustments from one side only, making installations more efficient. The innovative rotating wedge system simplifies the process of ensuring that glass panels are perfectly true and plumb, enhancing the overall quality of your installation.

Dimensions & Specifications

Specification	Measurement
Length	5000mm
Glass Thickness Compatibility	12mm to 21.52mm
Adjustment Range	38mm
Weight	32.0 kg
Width	127.0mm
Depth	65.0mm
Material	Aluminium
Material finish	Satin

Usage Instructions

To adjust the glass panels, simply insert the adjustment tool into the slot on the rotating wedge. This allows you to align the glass perfectly without the need for extensive handling or multiple adjustments.

Important Shipping Information

This product must be transported on a long pallet that covers three spaces to prevent damage during transit. A delivery surcharge will apply to orders containing this product.

FAQs

• What is the maximum glass thickness this channel base can accommodate?
  This channel base can accommodate glass panels with thicknesses ranging from 12mm to 21.52mm.
• How long is the adjustable channel base?
  The adjustable channel base is 5000mm long.
• Is the adjustment process easy?
  Yes, the channel base features a rotating wedge system that allows easy adjustments from one side only.
