Premium 90° Weld Bend for 88.9mm Outside Diameter Tube - Durable Steel Construction for Handrailing and Tubular Applications

Product Overview

This Premium 90° Weld Bend is specifically designed to fit 88.9mm outside diameter tubes, featuring a robust steel construction that ensures durability and reliability in various applications.

Typical Uses

• Handrailing
• Street furniture
• Protection barriers
• All types of tubular constructions

Features and Benefits

• Self Colour: Prepared for welding, allowing for seamless integration into existing structures.
• Smooth Streamlined Finish: Suitable for installation in painted, galvanised, polyester, powder-coated, or chrome-plated environments.
• Efficient Design: Enables tight bends and curves, eliminating sharp mitred corners and distortion commonly seen in tubes.
• Permanent and Strong Joint: Provides a neat, safe, and permanent joint with chamfered edges for ease of welding.

Dimensions & Specifications

Specification	Measurement
Outside Diameter	88.9mm
Nominal Bore	80mm
Wall Thickness	3.2mm
Radius	119mm
weight	1.24 kg
length	88.9mm
width	80.0mm
material	Mild Steel
material finish	Raw Steel

Technical Specifications

• Material: High-performance steel
• Finish: Self-colour, prepared for welding

FAQ

What is the purpose of using a weld bend?

A weld bend allows for smooth transitions in tubular constructions, reducing the risk of sharp corners and enhancing the structural integrity.

Can this weld bend be used outdoors?

Yes, the weld bend's durable steel construction makes it suitable for various environments, including outdoor applications.

Is it easy to weld?

Yes, the chamfered edges facilitate easy welding, ensuring a strong and permanent joint.
