Premium Heavy Duty Internal Mechanism Aluminium Drop Bolt with Height Adjustability and Corrosion-Resistant Handle

Product Overview

This premium aluminum drop bolt features an internal mechanism designed to provide secure locking for various gate types. Its silver finish adds a sleek look while ensuring durability and functionality.

Key Features

• Height adjustability of the drop bolt: 100 mm
• Internal drop bolt constructed from high-quality aluminum
• Throw length of 120 mm for effective locking
• Robust steel handle with black overmoulded polyamide for enhanced ergonomics and corrosion protection
• Internal push spring ensures perfect closure, even in case of dirt blockage
• Fast and easy installation with just 2 screws
• User-friendly operation at a convenient height
• Compatible with gate profiles: 40x40 mm, 50x50 mm, 60x60 mm, and 60x40 mm
• For profiles of 40 x 40 mm and 40 x 60 mm: maximum wall thickness of 2 mm
• For profiles of 50 x 50 mm and 60 x 60 mm: accommodates wall thicknesses up to 3 mm

Dimensions & Specifications

Specification	Measurement
Height Adjustability	100 mm
Throw Length	120 mm
Compatible Profiles	40x40 mm, 50x50 mm, 60x60 mm, 60x40 mm
Max Wall Thickness (40x40 mm)	2 mm
Max Wall Thickness (50x50 mm & 60x60 mm)	3 mm
Weight	2.05 kg

Benefits

This drop bolt is designed for optimal security and ease of use. The internal mechanism ensures that the gate closes securely, while the corrosion-resistant handle provides durability, making it ideal for outdoor applications.

FAQ

• What gate profiles are compatible with this drop bolt?
  This drop bolt is compatible with profiles of 40x40 mm, 50x50 mm, 60x60 mm, and 60x40 mm.
• How is the drop bolt installed?
  The installation is straightforward and requires only 2 screws for mounting.
• What is the maximum wall thickness for installation?
  For profiles of 40 x 40 mm and 40 x 60 mm, the maximum wall thickness is 2 mm; for 50 x 50 mm and 60 x 60 mm, it is 3 mm.
