Premium Heavy Duty Steel Cable Protection Ramp for Hoses - Accommodates 2 x 170mm Hoses with 44 Tonnes Load Capacity

Cable Protection Ramps

The Premium Hose and Cable Ramp is the central steel bridge for the modular ramp system designed to accommodate larger diameter hoses up to a maximum diameter of 170 mm.

This special steel bridge can accommodate 2 x 170 mm diameter hoses/cables. With the rubber elements of this system, it is possible to build a ramp with a length of 3400 mm, which allows most cars to cross the ramp without getting 'beached'.

The design allows the front wheel to still be in the rubber blocks when the rear wheel goes up the front edge of the ramp. The 7mm thick steel is galvanized with a yellow powder coating over (yellow is RAL1028).

Dimensions & Specifications

Specification	Measurement
Dimensions	360 x 400 x 175 mm
Weight	30 kg
Max Load	44 Tonnes
Channels	170mm width x 170mm depth
Colour	RAL1028 Yellow

This product has been redesigned and upgraded to 7mm thick steel.

Technical Specifications

• Accommodates larger diameter hoses up to 170 mm
• Designed for safe and easy access for vehicles
• Durable construction for long-lasting use
• Modular ramp system for flexibility in setup

FAQs

• What is the maximum load capacity? The maximum load capacity is 44 Tonnes.
• What size hoses can this ramp accommodate? This ramp can accommodate hoses with a maximum diameter of 170 mm.
• What material is used in the ramp? The ramp is made from 7mm thick galvanized steel with a yellow powder coating.
