Premium Industrial Gate Lock with Stainless Steel Mechanism and Adjustable Bolt for 30-50mm Box Section

Product Overview

This Premium Industrial Gate Lock is designed to fit 30-50mm box sections, ensuring a secure and reliable locking mechanism for your industrial gates. Made with high-quality aluminium housing and a solid stainless steel mechanism, this gate lock is a standard choice for industrial applications.

Key Features

• High-quality aluminium housing with stainless steel mechanism
• 20 mm continuous adjustability of the bolts for perfect latching
• Solid stainless steel deadbolt with a 23 mm throw for secure locking
• Anodized aluminium handle pair included for durability
• Easy installation with recommended Drill-Fix drilling jig

Technical Specifications

• ISO 9227 KTL/E-coated lock box withstands 1000 hours of salt spray test
• Self-latching daybolt can be easily changed for left or right installation
• Key-operated self-latching bolt for added security
• 4-hole fixing with two hexagon socket head screws
• 60 mm center distance of the bolts
• Continuous adjustment of the daybolt up to 20 mm without dismounting the lock box
• Throw of the dead bolt: 23 mm in one turn of the key
• Stainless steel mechanism for enhanced durability

Dimensions & Specifications

Specification	Measurement
Bolt Throw	23 mm
Center Distance	60 mm
Adjustability	20 mm
Weight	1.39 kg
Length	160.0mm
Width	90.0mm
Depth	31.0mm

Frequently Asked Questions

1. Can this lock be installed on both left and right opening gates?

Yes, the self-latching daybolt can be easily changed for left or right installation.

2. What is the material of the lock?

The lock features high-quality aluminium housing and a stainless steel mechanism for durability and security.

3. How secure is this gate lock?

With a solid stainless steel deadbolt and a throw of 23 mm, this gate lock provides excellent security for industrial applications.
