Premium 90° Weld Bend for 114.3mm Outside Diameter Tube with Smooth Finish for Easy Installation

Product Description

This Premium 90° weld bend is designed to suit tubes with an outside diameter of 114.3mm. It is perfect for a variety of applications, including handrailing, street furniture, protection barriers, and all types of tubular constructions. The smooth streamlined finish allows for installation in any environment, whether the structure is painted, galvanized, polyester coated, or even chrome plated.

The use of these elbows enables tight bends and curves, effectively resolving the problem of sharp mitred corners or distortion that can occur on tubes when radiused. They provide a neat, safe joint that is permanent and strong, with the added benefit of chamfered edges for ease of welding.

Dimensions & Specifications

Specification	Measurement
Outside Diameter	114.3mm
Nominal Bore	100mm
Wall Thickness	3.6mm
Radius	152mm
weight	2.19 kg
length	114.3mm
width	100.0mm
material	Mild Steel
material finish	Raw Steel

Technical Specifications

• Self-colour and prepared for welding
• Chamfered edges for ease of welding
• Suitable for various coatings and finishes

Applications

• Handrailing
• Street furniture
• Protection barriers
• All types of tubular constructions

FAQ

• Q: Can this weld bend be used for outdoor applications?
  A: Yes, it is suitable for various environments, including outdoor applications.
• Q: Is this product easy to install?
  A: Yes, the smooth finish and chamfered edges allow for easy welding and installation.
• Q: What is the wall thickness of the weld bend?
  A: The wall thickness is 3.6mm.
