Premium Anti-Panic Lock for 40-60mm Box Section with Stainless Steel Mechanism and Half Handle

Product Overview

The Premium Anti-Panic Lock is designed to fit box sections measuring 40 - 60mm. Constructed with an aluminum housing and featuring a stainless steel mechanism, this lock provides enhanced security for emergency exits. The lock is equipped with a push pad, handle, or push bar that allows for the deadlock to be overridden, ensuring quick and easy access in emergencies.

Key Features

• ISO 9227 KTL / E-coated lock box withstands up to 1000 hours of salt spray testing for durability.
• Self-latching daybolt can easily be changed for left or right-handed operation.
• Deadbolt has a 23 mm throw, operable with a single turn of the key.
• Key-operated self-latching bolt for added security.
• Fixed with a 4-hole design using two hexagon socket head screws.
• 60 mm center distance between bolts for compatibility.
• Continuous adjustment of the daybolt up to 20 mm without dismounting the lock box.
• Stainless steel mechanism tested for up to 500,000 movements.
• Available in EN179 certified configuration.
• Panic function E / Switch function for versatile use.

Technical Specifications

Specification	Measurement
Box Section Compatibility	40 - 60 mm
Deadbolt Throw	23 mm
Center Distance	60 mm
Weight	1.41 kg
Length	160.0mm
Width	90.0mm
Depth	31.0mm

Frequently Asked Questions

• Can this lock be used on both left and right doors?
  Yes, the self-latching daybolt can be easily changed for left or right-handed operation.
• What is the warranty on this lock?
  Details regarding warranty can typically be provided by the retailer.
• How many operations can this lock withstand?
  The lock mechanism has been tested for durability up to 500,000 movements.
