Premium Durable Dock Bumper with Low Friction Panel, 750 x 250 x 115 mm, Heavy Duty Design for Concrete and Steel Applications

Durable Dock Bumper

The Premium Dock Bumper is designed for superior performance, featuring a low coefficient of friction front panel made of 40 mm thick ultra-high molecular weight polyethylene. This durable bumper is ideal for protecting loading docks and provides a reliable buffer against impacts.

Details:

• Dimensions: 750 x 250 x 115 mm
• Weight: 21.5 kg

This bumper is sold as a single part and does not include a back plate or fixings. However, compatible back plates and fixings are available for purchase.

The installation method varies based on whether you wish to secure the bumper directly to a concrete wall/bay or use a steel back plate.

Installation Options

Direct Installation to Concrete Wall/Bay

Fixings Required:

• 3 x Through Anchor Stud M20 X 220mm
• 3 x M24 Washer

Installation Using Steel Back Plate

For installation using a steel back plate, the following parts are required:

• 1 x Steel Back Plate
• 3 x M24 Washer
• 3 x M24 x 100 mm Stud
• 6 x M16 x 125mm Through Anchor Stud
• 3 x M24 Nut
• 2 x Washer (50mm OD X 16mm ID x 3mm)

Dimensions & Specifications

Specification	Measurement
Length	750 mm
Width	250 mm
Height	115 mm
Weight	21.5 kg

Technical Specifications

• Material: Ultra-high molecular weight polyethylene
• Friction: Low coefficient of friction front panel
• Application: Ideal for concrete and steel surfaces

FAQs

Q: Can the front panel be replaced?

A: Yes, the front yellow area can be replaced if damaged or worn.

Q: Is a back plate necessary for installation?

A: It depends on the installation method; a back plate is recommended for additional support.

Q: What fixings are compatible with this bumper?

A: Various fixings are compatible, including through anchor studs and M24 washers.
