Premium Fiftylock Insert Kit for 50mm Box Section - Stainless Steel Mechanism and Adjustable Daybolt

Product Overview

The Premium Fiftylock Insert Kit is designed specifically for 50mm box sections and features a robust powder-coated finish for enhanced durability. This kit is equipped with a stainless steel lock mechanism that includes a cover plate to prevent dirt penetration, ensuring a reliable and long-lasting performance.

Key Features

• Stainless steel lock mechanism with dirt-resistant cover plate
• Components include hook, front plate, and latch bolt made from stainless steel
• Backset of 30 mm for mounting in profiles with a depth of 50 mm or more
• Continuous adjustment of the daybolt up to 10 mm without dismounting the lock
• Key-operated self-latching bolt for enhanced security
• Easy left or right changing of the self-latching daybolt
• Throw of the hook measures 21 mm
• Center distance between the cylinder and the handle is 92 mm
• Compatible with all Europrofile cylinders
• Handles available separately for customization
• Optional cover shield for handle and cylinder holes available in aluminium, polyamide, or stainless steel
• UNIWING-compatible design for versatile applications

Dimensions & Specifications

Specification	Measurement
Backset	30 mm
Throw of Hook	21 mm
Center Distance	92 mm
Weight	1.6 kg
Length	220.0mm
Width	47.0mm
Depth	21.0mm

Technical Specifications

• Material: Stainless steel and powder-coated finish
• Color: Black (Powder Coated RAL 9005)

FAQ

Q: Is this insert kit compatible with all Europrofile cylinders?

A: Yes, the Premium Fiftylock Insert Kit is compatible with all Europrofile cylinders.

Q: Can I adjust the daybolt without removing the lock?

A: Yes, the kit allows for continuous adjustment of the daybolt up to 10 mm without dismounting the lock.

Q: Are handles included in the kit?

A: No, handles must be ordered separately to customize your installation.
