Premium Motorised Electrical Dropbolt with Vandal-Proof Aluminium Housing and Automatic Obstacle Detection for Enhanced Security

Product Overview

This Premium Motorised Electrical Dropbolt is designed for superior security and reliability. Featuring a vandal-proof, powder-coated aluminium housing, it ensures durability and protection against environmental elements. This dropbolt is engineered to be connected to the warning light on automated gates, providing a minimum 3-second pre-warning signal for enhanced safety.

Key Features

• Vandal-proof, powder coated aluminium housing for durability
• Connects to warning light on automated gates for safety
• Automatic detection and memorisation of continuous or pulse signal
• Mechanical release available (by key) in case of emergency
• Fitted with relay for drop bolt detection
• Obstacle detection with automatic stop of the drop bolt if pressure exceeds 18 kg
• Throw length: 115 mm
• Drop bolt diameter: 20 mm
• Compatible with gate profiles of 40 mm or more
• Vertical mounting capability
• Power consumption: 25 W / Standby: 0.2 W
• Includes 5 m cable for easy installation
• Comes with a standard cylinder for added security

Dimensions & Specifications

Specification	Measurement
Throw Length	115 mm
Drop Bolt Diameter	20 mm
Power Consumption	25 W
Standby Power	0.2 W
Cable Length	5 m
Weight	4.21 kg
Length	585.0mm
Width	65.0mm
Depth	20.0mm

Technical Specifications

• Vertical mounting option for versatility
• Mechanical release by key for emergency situations
• Compatible with gate profiles of 40 mm or more
• Obstacle detection feature for enhanced safety

FAQs

1. Can this dropbolt be used with any gate?

This dropbolt is designed for use with gate profiles of 40 mm or more.

2. How is the dropbolt powered?

The dropbolt operates at a power consumption of 25 W, with a standby power of 0.2 W.

3. What happens if there is an obstacle during operation?

The dropbolt features an obstacle detection mechanism that stops the bolt if pressure exceeds 18 kg.
